The Garmach AGP-5R spring onion planter is a compact, 5-row chain-driven machine designed for small and medium-sized farms. Equipped with tines with diameters of 22, 28, and 36 mm (with the option of custom sizes), it allows planting spring onions, garlic, broad beans, saffron, and a variety of flowering bulbs. It offers adjustable row spacing (200-220 mm), seed spacing (90-200 mm), and planting depth (up to 160 mm). Weighing 260 kg and measuring 2000 × 1550 × 950 mm, it requires a 28 kW tractor and delivers a yield of 0.2 ha/h. Its simple design allows for easy repairs and modifications.
Product Features
The Garmach AGP-5R spring onion planter is a versatile agricultural machine that:
Has a 5-row design, ideal for small and medium-sized farms
Its completely mechanical, simple construction allows for easy repairs and modifications
It is equipped with a chain system with standard tines of 22 mm, 28 mm, and 36 mm
It offers the option of ordering chains with non-standard tine diameters, tailored to individual needs
Provides smooth row spacing adjustment from 200 mm to 220 mm
Allows seed spacing to be adjusted from 90 mm to 200 mm, with the option of selecting 3 custom settings
Allows for gradual adjustment of planting depth in 20 mm increments, up to a maximum of 160 mm
It has a frame width of 980 mm, making it a compact solution
It is equipped with 2 operator seats
It is versatile – suitable for For planting spring onions, garlic, broad beans, saffron, gladioli, tulips, and other tubers
Requires a 28 kW tractor for efficient operation
Product Benefits
Using the Garmach AGP-5R planter on your farm brings a number of tangible benefits:
Significant time and labor savings compared to manual planting
Versatile use – one machine for various types of tubers and bulbs
Precise planting material placement thanks to the chain system
Adaptable operating parameters to various crops and soil conditions
Smooth adjustment of row spacing and seed spacing provides flexibility in crop planning
Simple mechanical design facilitates maintenance and repairs without the need to call a specialist service center
Compact dimensions enable easy storage and transport
A capacity of 0.2 ha/hour allows for efficient management of even larger areas
Possibility of independent modifications and adaptation of the machine to the specific needs of the farm
Compatible with popular models 28 kW tractors
Long service life thanks to its robust design and high-quality workmanship
Technical Specifications
Device Type: Chain planter for spring onions and other bulbs
Model: Garmach AGP-5R
Operating Parameters:
Number of rows: 5
Row spacing: adjustable from 200 mm to 220 mm (continuously adjustable)
Seed spacing: from 90 mm to 200 mm (3 custom settings available)
Planting depth: adjustable in 20 mm increments to a maximum of 160 mm
Capacity: 0.2 ha/hour
Design:
Frame width: 980 mm
Planting mechanism type: Chain with carriers
Standard carrier diameters: 22 mm, 28 mm, 36 mm
Number of operator seats: 2
Parameters Physical:
Weight: 260 kg
Dimensions (L × W × H): 2000 × 1550 × 950 mm
Requirements:
Required tractor power: 28 kW
Applications:
Planting spring onions
Planting garlic
Planting broad beans
Planting saffron
Planting flower bulbs (gladioli, tulips, and others)
The Garmach AGP-5R spring onion planter is the ideal solution for small and medium-sized farms looking for versatile, reliable, and easy-to-use equipment for precise planting of various bulbs. Thanks to its simple mechanical design, adjustable options, and robust construction, it is a worthwhile investment that will significantly increase work efficiency and crop quality.
